Description
Rode NTG5 Location Recording Kit - Black Spec:
| Brand | Rode |
|
Acoustic Principle |
RF-bias condenser |
|
Active Electronics
|
RF-bias demodulation |
|
Polar Pattern |
Supercardioid shotgun
|
|
Frequency Response |
20 Hz - 20 kHz
|
|
Frequency Response |
80 Hz - 20 kHz ±3 dB |
|
Output Impedance |
25 Ω |
| Signal-to-noise Ratio |
84 dB |
|
Equivalent Noise |
10 dB SPL (A-weighted, as per IEC651) |
| Input SPL @ 1% THD |
130 dB SPL (1kHz @ 1% THD, 600 Ω load) |
|
Power Requirements
|
2 mA @ 48V phantom power |
| Sensitivity |
-23.5 dB re. 1 Volt/Pascal or Better (66 mV @ 94 dB SPL @ 1 kHz) |
| Dimensions |
NTG5: 203 (H) x 19 (W) x 19 (D) PG2-R: 240 (H) x 60 (W) x 117 (D) |
| Weight |
NTG5: 76 PG2-R: 224 |
| Box Contains | 1 x NTG5 Microphone 1 x Foam Windshield 1 x PG2-R Grip 7 1x RM5 Microphone Clip 1xWS10 Windshield 1 x PG2-R Pro Cable 1xZP1Small Pouch Bag |
| Model | NTG5-Kit |
| Color | Black |
| Warranty | 60 Month |
Overview For Rode NTG5 Location Recording Kit - Black
Revolutionary Acoustic Design
The NTG5 features a revolutionary acoustic design unlike any other shotgun microphone. Circular acoustic perforations are utilised in place of linear slots, delivering greater acoustic transparency and a natural, uncoloured sound for superb performance in a wide variety of recording applications.
A Boom Operator’s Dream
The NTG5 features a short, super-lightweight aluminium body (just 76g!), making it one of the most compact professional shotgun mics available – a dream for boom operators who find themselves on long shoots, or filmmakers and sound recordists looking for a more portable and lightweight rig that delivers spectacular, broadcast-grade audio.
The Perfect Location Recording Mic
With a tightly controlled frequency response, low self-noise, highly directional supercardioid polar pattern, and smooth off-axis response, the NTG5 sounds spectacular in a wide variety of applications. It also boasts RF-bias technology and conformal coating on the electronics, which protect the microphone from moisture and humidity and ensure it is incredibly reliable even iin harsh environmental conditions. The NTG5 is the perfect mic for location recording and demanding filmmaking scenarios where superlative audio is imperative. No excuses.
