Description
Rode Caster Video | Video and Audio Production Console - Black Spec:
| Brand | Rode |
| Audio |
Analog Audio Inputs: 2 combo jacks (microphone, line or instrument) with Revolution Preamps™
Wireless Audio Inputs: 2 Series IV wireless receivers Digital Audio Inputs: Analog Audio Outputs: 20 possible audio sources (9 stereo channels simultaneously): combo 1 and 2 (can be combined for stereo), wireless 1 and 2, video clips, sounds, HDMI 1, 2, 3 and 4 (each can be split for two mono), Bluetooth,3 USB audio interfaces (computers), 2 hosting USB audio devices (microphones) 12 Outputs with Custom Routing: live mix, headphone 1, headphone 2, recording, monitors, USB Main, USB Chat, USB 1, 2, 4 and 5, Bluetooth Note: Each output can be independently configured with custom level, mute status and level offset settings for each of the 9 inputs
Audio Processing:
APHEX® VoxLab™ Processing: per channel Frequency range: 20Hz – 20kHz Recording Sample Rate / Bit Depth: 48kHz / 24-bit |
|
Video
|
Video Input Feeds: 6 simultaneous HDMI Inputs: 4 type-A (HDMI 1.4b) USB (UVC) Inputs: 2 multi-function USB-C for UVC video HDMI Outputs: Video Input Frame Rates: 1920x1080p: 23.97, 24, 25, 29.97, 30, 50, 59.94, 60 Video Output Frame Rates: Video Streaming Standards: Video Engine Colour Space / Bit Depth: 4:4:4 RGB / 8-bit HDMI Input Colour Space / Bit Depth: 4:4:4 RGB, 4:4:4 YUV, 4:2:2 YUV / 8, 10, 12-bit USB Input Colour Space: 4:2:2 YUV, 4:2:0 YUV (NV12) HDMI Output Colour Space / Bit Depth: 4:4:4 RGB, 4:4:4 YUV / 8-bit USB Output Colour Space / Bit Depth: 4:2:2 YUV / 8-bit Format and Frame Rate Converters: On all HDMI and USB inputs |
| Streaming, Recording and Software |
Direct Streaming: Real Time Messaging Protocol (RTMP/RTMP) over Ethernet or Wi-Fi Supported Platforms: Network: Storage Media: Video Recording: Isolated (ISO) Video Recording: Audio Recording: Stereo mix WAV audio file Multitrack Audio Recording: 9 independent stereo WAV audio files RØDE Central Companion Software: Compatible Operating Systems: |
| Switching |
Total Number of Layers: 9 simultaneous in Preview and Program Downstream Keyers: 2 (overlays and logo) Chroma Keyers (Green and Blue): 2 Media Players: 2 simultaneous Transitions: SMPTE wipes, dip and fade True Preview: Display complete scenes and overlays simultaneously in preview and program Generated Borders: All scenes Multiview: Media Player: Bluetooth: 5.3 (for stereo audio input or phone calls) |
| Power and Mechanical |
Power Supply Requirements: USB-C PD 60W, 20V 3A
Dimensions:Length: 132.5 Width: 305.9 Height: 61.4 Weight: 1257 |
| Box Contains | 1 x RØDECaster Video 1 x SC27 2 x External Antenna 1 x Power Supply |
| Model | JF0013936 |
| Color | Black |
| Warranty | 60 Month |
Overview For Rode Caster Video | Video and Audio Production Console - Black
All-in-One, All at Once
The ultimate all-in-one content creation tool, the RØDECaster Video is the first in its class to seamlessly blend comprehensive video and audio production into a single, compact device. Offering unmatched flexibility in switching, mixing, processing, recording and streaming multiple video and audio sources at once, it is the perfect centrepiece for any content creation setup.
Professional Production Made Simple
It’s never been easier to create professional productions with incredible video and audio. The RØDECaster Video’s intuitive interface and dynamic touchscreen give you hands-on control of every element of your show, from switching video and configuring complex multi-source layouts to mixing and processing your audio.
Switch it Up
With simultaneous control over six different video feeds, the RØDECaster Video allows you to seamlessly switch between cameras, consoles and other visual inputs to fully immerse your audience in your show. Cut between your shots instantly or apply tasteful fades, dips and wipes with fully customisable transitions – you can even sequence your show with live previews of each feed before you make the switch.
Set the Scene
The RØDECaster Video is the first of its kind to offer an intuitive scene-based switching architecture, making it easier than ever to customise and configure complex video arrangements and switch to them at the press of a button.
Integrated Professional Audio
With the ability to mix, process and route up to nine audio sources at once, the RØDECaster Video sets a new standard for power and flexibility in audio production. Each channel has access to a full suite of studio-grade effects and processors powered by APHEX®, allowing you to sculpt your dream sound and deliver polished, professional results every time.
Expanded USB Inputs
The RØDECaster Video features two flexible USB-C ports for expanding your production with extra video and audio devices. You can connect compatible USB webcams, capture cards and other UVC video devices, as well as RØDE USB microphones and even the RØDECaster Pro II and RØDECaster Duo!
Always Evolving
Now with NDI support, PTZ camera control and advanced auto-switching, the RØDECaster Video makes multi-cam podcasting and streaming effortless. NDI integration also extends to the RØDE Capture app, instantly turning your iPhone’s front and rear cameras into a professional, multi-angle source.
Intuitive Interface
The large high-resolution touchscreen and versatile rotary encoder provide intuitive hands-on control over every aspect of your production, from applying transitions and previewing your inputs to adjusting volume levels and configuring settings.
Wireless Remote Control
For setups where you can’t be close to the console, the RØDECaster Video boasts complete wireless remote control via the RØDECaster app, allowing you to switch inputs, adjust settings and configure complex scenes from your computer.
