Description
Tenda Security Pan - Tilt Camera Smart Guardian - CP3 Pro - Wi-Fi - 2K - 3MP - White Spec:
Camera | Image Sensor
1/3 Progressive Scan CMOS sensor Day and Night
ICR type |
Lens |
Focal Length
4mm Aperture
F2.0 FOV
Horizontal : 78°, Vertical : 41.8°, Diagonal : 95° |
Supplementary Light
2 IR Lights Supplementary Light Distance
Up to 10 m/32 ft (depending on environment) IR Wavelength
850nm Night Vision Mode
Black & White Mode |
|
Video |
Video Encoding Format
H.265, H.264 Main Stream Resolution
2304 × 1296, 1920 × 1080, 1280 × 720 Sub Stream Resolution
640 x 360 , 352 x 288 , 320x240 Frame Rate
1-30fps, Default 20fps Bit Rate
512kbps -- 4096kbps Bit Rate Control
CBR,VBR |
Audio Encoding Format
G.711A, G.711U, AAC Audio Sampling Rate
8 kHz Audio Communication
Two-way Audio, One-touch Call |
|
Image |
Image Enhancement
DWDR, BLC, HLC, 3D DNR Privacy Mask
4 Areas |
Network |
ONVIF
Support Protocols
TCP/IP, UDP, ICMP, HTTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, ARP |
Pan&Tilt |
Pan Movement Range
0°--355° Tilt Movement Range
-65°--90° Preset
6 Patrol
Panoramic Patrol, Preset Patrol |
Wi-Fi |
Antenna
Internal antenna Wireless Standard
IEEE 802.11 b/g/n/ax Transmission Rate
Up to 287Mbps Channel Width
20/40 MHz Modulation
DSSS/OFDM/OFDMA Frequency Band
2.4GHz: 2412MHz-2472MHz(CH1-CH13) Transmit Power
2.4GHz: <0.1W(EIRP) Security
64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK |
Alarm |
Smart Detection
Motion Detection, Tempering Detection, Human Detection, Cry Detection, Pet Detection Smart Linkage
Sound&light Alert, Human Tracking DIY Audio
3 Customized Audios |
Interface |
Audio Input
Built-in MIC, adjustable microphone volume Audio Output
Built-in Speaker, 68 dBA (Alarm sound at 1 meter), adjustable sound level Storage
Built-in Micro SD Card Slot, Up to 256 GB Reset Button
Support LED Indicator
Dual Color (red & blue) |
General |
Power
9V DC, 1A, Ø5.5mm&Ø2.1mm Power Plug Material
Plastic Smart Integration
Amazon Alexa Product Dimension
103mm x 88mm x 88mm (4.1'' × 3.5'' × 3.5'') Package Dimension
100mm x 100mm x 163mm (4.0'' × 4.0'' × 6.5'') Product Weight
200g (0.44lb) With Package Weight
420g (0.93lb) Installation Method
Desktop, Ceiling Mounting Certification
CE, RoHS, FCC, RCM, UKCA Temperature
Operating Temperature: -10°C ~ 45°C (14°F ~ 113°F) Humidity
Operating Humidity: 10% ~ 95% RH (non-condensing) Package Contents
Camera |
Model | CP3 Pro |
Warranty | 12 Months |
Overview For Tenda Security Pan - Tilt Camera Smart Guardian - CP3 Pro - Wi-Fi - 2K - 3MP - White
Cover Every Corner of Your Home With The Pan/Tilt
New WiFi6 Technology, Ultra-low Network Delay

Easily Call Family Members With The One-touch Call Button
Auto Targeting and Tracking

Active Light and Sound Alarms for Enhanced Defense

Support Desktop, Ceiling and Wall Mounting
