Harman Kardon Citation MultiBeam™ 700 - Black

General Specifications

Note: CITATION MULTIBEAM 700 is in compliance with European Commission Regulation (EC) No 1275/2008 and (EU) No 801/2013.
Power consumption: Yes
Network Standby: 2.0 Watts
Time to networked standby: 18 minutes
Networked standby: in the condition of any wireless connection of the device is activated, if no provide any audio or video signal to the device, it will automatically into networked standby mode in 18 minutes. Any audio or video recover will bring device from standby to operation mode.

Audio Specifications

Dimensions

Dimensions (W x H x D): 790 x 65 x 130mm (31.1" x 2.6" x 5.1")
Weight: 3.7kg (8.1lb): Yes

Control and Connection Specifications

Bluetooth® version: 4.3
Bluetooth transmitter frequency range: 2402 – 2480MHz
Bluetooth transmitter power: <10dBm
Bluetooth transmitter modulation: GFSK,π/4 DQPSK, 8DPSK
Wireless network: 802.11 a/b/g/n/ac (2.4GHz/5GHz)
2.4G Wi-Fi transmitter frequency range: 2412 – 2472MHz (2.4GHzISM Band, USA 11 Channels, Europe and others 13 Channels)
2.4G Wi-Fi transmitter power: <20dBm
2.4G Wi-Fi modulation: DBPSK, DQPSK, CCK, QPSK, BPSK, 16QAM, 64QAM
5G Wi-Fi transmitter power: <23dBm
5G Wi-Fi modulation: QPSK, BPSK, 16QAM, 64QAM, 256QAM
5G Wi-Fi transmitter frequency range: 5.15 - 5.35GHz, 5.470 - 5.725GHz, 5.725 - 5.825GHz

Battery

Power Supply: 100-240V~50/60Hz
Power consumption in sleep mode: <2.0 Watts
